3DSS

Type single phase 220-240V ~ Hz50	Motor power		Capacity and head										Length
	Motor power		L/min	0	8	17	25	30	33	42	50	63	Length
	KW	HP	m³/h	0	0.5	1	1.5	1.8	2	2.5	3	3.8	mm
3DSS4.0/35-D24/400	0.4	0.54	Head(m)	38	37.5	36	33	30	28	22	15	4	462x75
3DSS4.0/45-D48/500	0.5	0.68		45	40	38	35	33	30	25	21	15	483x75
3DSS4.0/60-D48/600	0.6	0.82		62	61	60	57	56	52	44	33	16	525x75
3DSS4.0/80-D48/750	0.75	1		80	78	75	70	62	60	50	40	10	588x75
3DSS4.0/80-D72/750	0.75	1		80	78	75	70	62	60	50	40	10	588x75
3DSS4.5/100-D72/1000	1.0	1.36		100	90	82	74	70	68	61	53	45	670x75
3DSS4.5/110-D110/1000	1.0	1.36		110	90	82	76	74	72	65	58	47	670x75
3DSS5.0/140-D110/1500	1.5	2		140	114	105	98	93	91	85	75	55	755x75

Model	Voltage(V)	Best input voltage (DC) (V)	Motor power		Max Flow (M³/H)	Max Head (M)	Outlet (IN)	Cable (m)	Solar panel
Model	Voltage(V)	Best input voltage (DC) (V)	KW	HP	Max Flow (M³/H)	Max Head (M)	Outlet (IN)	Cable (m)	Open circuit voltage (VOC) (V)	Power
3DSS4.0/35-D24/400	24V	30-48V	0.4	0.54	4	38	1.25"	2m	<50V	≥1.3" Pump power
3DSS4.0/45-D48/500	48V	60-90V	0.5	0.68	4	45	1.25"	2m	<100V	≥1.3" Pump power
3DSS4.0/60-D48/600	48V	60-90V	0.6	0.82	4	60	1.25"	2m	<100V	≥1.3" Pump power
3DSS4.0/80-D48/750	48V	60-90V	0.75	1	4	80	1.25"	2m	<100V	≥1.3" Pump power
3DSS4.0/80-D72/750	72V	90-120V	0.75	1	4	80	1.25"	2m	<150V	≥1.3" Pump power
3DSS4.5/100-D72/1000	72V	90-120V	1.0	1.36	4.5	100	1.25"	2m	<150V	≥1.3" Pump power
3DSS4.5/110-D110/1000	110V	110-150V	1.0	1.36	4.5	110	1.25"	2m	<200V	≥1.3" Pump power
3DSS5.0/140-D110/1500	110V	110-150V	1.5	2	5	140	1.25"	2m	<200V	≥1.3" Pump power
