4DSS

Type single phase 220-240V ~ Hz50	Motor power		Capacity and head												Length
	Motor power		L/min	0	33	50	67	83	100	117	133	150	233	283	Length
	KW	HP	m³/h	0	2	3	4	5	6	7	8	9	14	17	mm
4DSS5/35-D24/400	0.4	0.54	Head(m)	35	23	18	12	5	-	-	-	-	-	-	501x100
4DSS6/45-D48/500	0.5	0.68		45	34	30	23	14	2	-	-	-	-	-	523x100
4DSS6/58-D48/750	0.75	1		58	43	36	28	16	3	-	-	-	-	-	545x100
4DSS6/67-D72/750	0.75	1		67	54	47	34	19	3	-	-	-	-	-	566x100
4DSS6/80-D72/1000	1.0	1.36		80	65	58	45	26	3	-	-	-	-	-	597x100
4DSS6/105-D110/1000	1.0	1.36		105	83	75	53	38	3	-	-	-	-	-	641x100
4DSS6/135-D110/1500	1.5	2		135	108	83	57	38	3	-	-	-	-	-	707x100
4DSS9/80-D110/1500	1.5	2		80	66	62	55	46	39	30	22	6	-	-	582x100
4DSS22/24-D110/1500	1.5	2		24.5	24	23	22.5	22	21.5	21	20.5	19	15	12	548x100

Model	Voltage(V)	Best input voltage (DC) (V)	Motor power		Max Flow (M³/H)	Max Head (M)	Outlet (IN)	Cable (m)	Solar panel
Model	Voltage(V)	Best input voltage (DC) (V)	KW	HP	Max Flow (M³/H)	Max Head (M)	Outlet (IN)	Cable (m)	Open circuit voltage (VOC) (V)	Power
4DSS5/35-D24/400	24V	30-48V	0.4	0.54	5	35	1.25"	2m	<50V	≥1.3" Pump power
4DSS6/45-D48/500	48V	60-90V	0.5	0.68	6	45	1.25"	2m	<100V	≥1.3" Pump power
4DSS6/58-D48/750	48V	60-90V	0.75	1	6	58	1.25"	2m	<100V	≥1.3" Pump power
4DSS6/67-D72/750	72V	90-120V	0.75	1	6	67	1.25"	2m	<150V	≥1.3" Pump power
4DSS6/80-D72/1000	72V	90-120V	1.0	1.36	6	80	1.25"	2m	<150V	≥1.3" Pump power
4DSS6/105-D110/1000	110V	110-150V	1.0	1.36	6	105	1.25"	2m	<200V	≥1.3" Pump power
4DSS6/135-D110/1500	110V	110-150V	1.5	2	6	135	1.25"	2m	<200V	≥1.3" Pump power
4DSS9/80-D110/1500	110V	110-150V	1.5	2	9	80	1.5"	2m	<200V	≥1.3" Pump power
4DSS22/24-D110/1500	110V	110-150V	1.5	2	22	24	2"	2m	<200V	≥1.3" Pump power
