4DSP-A/D

Type single phase 220-240V ~ Hz50	Motor power		Capacity and head												Length
	Motor power		L/min	0	33	42	50	58	67	83	97	100	133	150	Length
	KW	HP	m³/h	0	2	2.5	3	3.5	4	5	5.8	6	8	9	mm
4DSP6-95-A220/D300-1100	1.1	1.5	Head(m)	95	80	75	70	60	50	35	10	1	-	-	674x100
4DSP6-135-A220/D300-1500	1.5	2		135	110	100	95	82	72	42	12	2	-	-	728x100
4DSP6-175-A220/D300-2200	2.2	3		175	150	135	120	110	100	60	15	3	-	-	827x100
4DSP6-175-A380/D550-2200	2.2	3		175	150	135	120	110	100	60	15	3	-	-	827x100
4DSP6-230-A380/D550-3000	3.0	4		230	190	175	160	140	120	75	20	5	-	-	955x100
4DSP9-80-A220/D300-1500	1.5	2		80	75	73	70	65	60	50	42	40	-	-	662x100
4DSP9-125-A220/D300-2200	2.2	3		125	110	105	95	85	80	60	50	45	15	2	769x100
4DSP9-125-A380/D550-2200	2.2	3		125	110	105	95	85	80	60	50	45	15	2	769x100
4DSP9-195-A380/D550-3000	3.0	4		195	175	165	160	150	140	120	105	100	40	5	962x100

Model	Voltage(V)	Best input voltage (DC) (V)	Motor power		Max Flow (M³/H)	Max Head (M)	Outlet (IN)	Cable (m)	Solar panel
Model	Voltage(V)	Best input voltage (DC) (V)	KW	HP	Max Flow (M³/H)	Max Head (M)	Outlet (IN)	Cable (m)	Open circuit voltage (VOC) (V)	Power
4DSP6-95-A220/D300-1100	300V	300/400V	1.1	1.5	6	95	1.25"	2m	<450V	≥1.3" Pump power
4DSP6-135-A220/D300-1500	300V	300/400V	1.5	2	6	135	1.25"	2m	<450V	≥1.3" Pump power
4DSP6-175-A220/D300-2200	300V	300/400V	2.2	3	6	175	1.25"	2m	<450V	≥1.3" Pump power
4DSP6-175-A380/D550-2200	550V	480/750V	2.2	3	6	175	1.25"	2m	<800V	≥1.3" Pump power
4DSP6-230-A380/D550-3000	550V	480/750V	3.0	4	6	230	1.25"	2m	<800V	≥1.3" Pump power
4DSP9-80-A220/D300-1500	300V	300/400V	1.5	2	9	80	1.5"	2m	<450V	≥1.3" Pump power
4DSP9-125-A220/D300-2200	300V	300/400V	2.2	3	9	125	1.5"	2m	<450V	≥1.3" Pump power
4DSP9-125-A380/D550-2200	550V	480/750V	2.2	3	9	125	1.5"	2m	<800V	≥1.3" Pump power
4DSP9-195-A380/D550-3000	550V	480/750V	3.0	4	9	195	1.5"	2m	<800V	≥1.3" Pump power
