Deep well pump
View More
| Model | AU-QB60 | AU-QB70 | AU-QB80 |
|---|---|---|---|
| Supply power | 220-240v/50hz | 220-240v/50hz | 220-240v/50hz |
| Input power | 370w | 550w | 750w |
| Max.head (m) | 35 | 45 | 52 |
| Max.flow (L/min) | 35 | 45 | 52 |
| Max.suct (m) | 8 | 8 | 8 |
| Max.dia particle (mm) | 3 | 3 | 3 |
| Outlet/inlet (mm) | 1″×1″ | 1″×1″ | 1″×1″ |
| Cable (m) | HO7RN-F 1.5M | HO7RN-F 1.5M | HO7RN-F 1.5M |
| Tank volume (liter) | 8L | 8L | 8L |
| Openning pressure (Bar) | 1.2 | 1.4 | 2.2 |
| Shutoff pressure (Bar) | 2.2 | 2.8 | 3.5 |
